Alternating Current: NEET 2023

Medium· AC Voltage Applied to a Series LCR Circuit· +4 / −1

The net impedance of circuit (as shown in figure) will be : Question diagram

Question diagram

A series circuit made of an inductor

\dfrac{50}{\pi}\ \mathrm{mH}

, a capacitor

\dfrac{10^{3}}{\pi}\ \mu\mathrm{F}

, a resistor

10\ \Omega

, connected to an ac source of

220\ \mathrm{V}

,

50\ \mathrm{Hz}

.
